100W 150W Raycus 3D CO2 Fiber Ring Jewellery Fiber Laser Marking/Engraver/Cutter/Marker/Printing/Cutting Machine CE FDA Standard Laser Engraving

Basic Info.

Model NO.	MAN-100
Type	Optical Fiber Laser Marking Machine
Marking Method	Scanning Marking
Cooling Mode	Air Cooling
Positioning Way	Red Light
Certification	Ce FDA SGS
Software	Ezcad Software
Markingspeed	7000mm
Marking Depth	0-0.5mm
Voltage	220V/50Hz
Repeat Frequency	10kHz- 100kHz
Transport Package	Wooden Box
Specification	Fiber Laser Marking Machine
Trademark	CNMANLASER
Origin	Shandong
HS Code	8456110090
Production Capacity	500 Set/Month

Product Description

100W 150W Raycus 3D CO2 Fiber Ring Jewellery Fiber Laser Marking/Engraver/Cutter/Marker/Printing/Cutting Machine CE FDA Standard Laser Engraving

TECHNICAL PARAMETER :

01	Power	10W/ 20W /30W
02	Product Name	Fiber Laser Marking Machine
03	Laser Brand	Raycus,MAX.IPG
04	Laptop Computer ( optional )	Including one laptop for each set, build-in laser marking software.
05	Laser Marking Machine Type	Portable, optional for desktop laser marking machine items.
06	Laser Wavelength	1064nm
07	Device Marking Area	110mmx110mm
08	Optional Marking Area	210mmx210mm / 310mmx310mm
09	Laser Marking Depth	≤5mm(depending on material and marking time).
010	Laser Marking Speed	≤7,000 mm/s
011	Minimum Line Width	0.01mm
012	Minimum Character	0.15mm
013	Repeated Precision	±0.003mm
014	Life-span of Fiber Laser Marking	100,000 hours
015	Beam Quality	M2 <1.5
016	Focus Spot Diameter	<0.01mm
017	Output Power of Laser	10%~100% continuously to be adjusted.
018	System Operation Environment	Windows XP / Win7(32/64bits) / Win8(32/64bits)/Win10.
019	Cooling Mode	Built-in fan for Air cooling.
020	Power Input	220V-50HZ(single phase) or 110V-60HZ(single phase).
021	Laser marking software	Ezcad professional marking software, English version.

DETAILS IMAGES :

Performance Features
1) With small size and compact structure, the 20w fiber laser marking machine is convenient to move.2) Long lifespan of fiber laser source: 100 000 hours 3) the 20w fiber laser marking machine has good scanning galvanometer, with good seal, small volume, compact.4) good Scaps controller, USB interface, swift and stable transmission, the machine can work with a Laptop.5) High Precision: upto 0.0012mm, bring you the fantastic and satisfied marking effect.6) Superior Laser Beam: the definition is 1 micron, 10 times as that of traditional products.7) No Consumables: One aluminum laser engraving machine can work for more than 10 years without any consumables.8) Fast Speed: 800 standard characters per second, is 3 to 5 times above that of traditional products.9) The fiber laser beam no need to adjust the laser optical path.10) Low consumption: <400W, is 1/25 ~ 1/10 times as that of Diode and YAG, more economized and environmental.11) Integrated Air Cooling System: The cooling effect is more excellent than the water cooling effect in YAG laser, the aluminum laser engravingmachine don't need maintenance.
SAMPLE SHOW :
Application Industry: Gold & Silver Jewellery, Sanitary Ware, Foof Packing, Tobacco Products, Medicine Packing, Medical Apparatus and industries,watches & glassware, auto accessories and electronic hardware.
Applicable Materials:
Gold & Sliver, Stainless Steel, Ceramic, Plastic, Glass, Stone, Leather, Cloth, Bamboo and so on.Typical case: Auto accessories marking, tobacco products marking, beer bottle marking, ring marking, electronic products marking and etc.

ABOUT US :
What can we do to serve our customers?
Pre-sale service:*****Free sample markingFor free sample making/testing, please send your samples to our company in China. Sample shipping cost should be paid by buyer.*****Progressing Solution DesignAccording to customer's product processing requirement, we can design the unique solution that supports higher manufacturing efficiency and betterprocessing quality for customer.
After-sale service:
*****36 Months Warranty of Laser Generator.*****English Version Installation Instructions.*****Offer training at our factory for free (you could visit us and learn.)*****Lifelong technical support online or by email and 24 hours online service to help you use our machine well.
If you are interested, or would like to know more information and products,please feel free to leave a message in the following blank space.
