Package Size 128.00cm * 101.00cm * 127.50cm Package Gross Weight 248.000kg 3000W Fiber Laser Welding Machine, Built-in W
Basic Info.
Model NO. LXW
Technical Class Continuous Wave Laser
Control Manual
Power Density Deep Penetration Welding
Laser Classification Optical Fiber Laser
Type Laser Mold Welding Machine
Average Consumed Power 2000/4000W
Pulse Width 0.1-50ms
Cooling Method Water Cooling
Wavelength 1064nm
Product Name Fiber Laser Welding Machine
Focal Spot Diameter 0.2-3.0mm
Adjustable Power Range 5-95%
Electricity Demand AC220V
Optimal Operating Environment Temperature 10-35 ° C, Humidity 20% -80%
Output Power Stability <2%
Laser Frequency 50Hz-5kHz
Center Wavelength 1070+-5nm
Transport Package Standard Plywood Case
Specification 760*780*790mm
Trademark LXSHOW
Origin China Shandong Jinan
Production Capacity 120set/Month
Packaging & Delivery
Package Size 128.00cm * 101.00cm * 127.50cm Package Gross Weight 248.000kg
Product Description

3000W Fiber Laser Welding Machine, Built-in Water Cooler

This machine is suitable for welding of gold, silver, titanium, nickel, tin, copper, aluminum and other metal and its alloy material, can achieve the same precision welding between metal and dissimilar metals, has been widely used in aerospace equipment, shipbuilding, instrumentation, mechanical and electrical products, automotive and other industries. Single wire welding is recommended for materials less than 2mm thick. If the weld seam is wider than 2mm and the welding height is better, double wire welding is recommended. 3000 power double-wire is recommended for ≥ 5 thickness.


Character

1.The energy density is high, the heat input is low, the amount of thermal deformation is small, and themelting zone and the heat-affected zone are narrow and deep.

2.High cooling rate, which can weld fine weld structure and good joint performance.

3.Compared with contact welding, laser welding eliminates the need for electrodes, reducing daily

maintenance costs and greatly increasing work efficiency.

4.The weld seam is thin, the penetration depth is large, the taper is small, the precision is high, the

appearance is smooth, flat and beautiful.

5.No consumables, small size, flexible processing, low operating and maintenance costs.

6.The laser is transmitted through fiber optics and can be used in conjunction with a pipeline or robot.

Technology Parameter

Laser powerLXW-500/750/800/1000W/1500W/2000W/3000W
Center wavelength1070+-5nm
Output power stability<2%
Laser frequency50Hz-5kHz
Adjustable power range5-95%
Beam quality1.1
Optimal operating environmentTemperature 10-35 ° C, humidity 20% -80%
Electricity demandAC220V
Output fiber length5/10/15m (Optional)
Cooling methodWater Cooling
Dimensions93*60*88cm
Weight200kg
Cooling water temperature20-25 ° C
Average consumed power2000/4000W
Pulse Width0.1-50MS
Focal Spot Diameter0.2-3.0mm
Wavelength1064nm
Warranty2 Years
Product nameFiber laser welding machine


Main Parts Au3tech laser gun
1 High-quality precision optical components are selected, and thebeam quality is excellent and stable.2 Cool appearance,ergonomic design, comfortable grip.3 Double protective lens design, better dustresistance.4 Straight line light spot, welding operation is simpler, welding firmnessis high, and the texture is beautiful.Au3tech control system
1 Easy installation, easy adjustment, excellent performance,complete solutions.2 Intelligent system, stable performance, simple operation, suitable for different kinds of metal processing.3 It supports modular, individual, automated and informative solutions.Water chiller
1 Relative leading product technology(complete laboratory and performance testing means), product specifications and actual performance good consistency.2 With multiple after-sales office in china and abroad, product service is more real-time and reliable.Raycus laser source
1 Famous laser brand all over the world2 High electronic-optical conversion efficiency, good beam quality, wide modulation frequency, high reliability, long life and maintenance-free.
Samples


Factory
About Jinan Lingxiu Laser Equipment Co., Ltd.

It is established in July 2004, owns more than 500 square meters of researching and office space, more than 32000 square meters factory.All machines , passed the European Union CE authentication, American certificate and are certified to ISO 9001. Products are sold to USA,Canada, Australia, Europe, South east Asia,Africa etc,more than 150 countries and areas,and supply OEM service for more than 30 manufactures.

Multi-Function 3000W Integrated Handheld Fiber Laser Welding Machine Price

Our Customers


Offline Exhibition

Multi-Function 3000W Integrated Handheld Fiber Laser Welding Machine Price

Certification Display
About machine quality, we have get the third party certification, and about the machine, we have 3 years machine warranty, if you need, we always here.

After-sales TeamFAQ

Q1 :How about warranty?

A1:2 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.


Q2:2 I don't know which one is suitable for me ?

A2:Please tell me

1) Your materials.

2) The thickness of your materials.

3) Size of welding line.


Q3:Payment terms?

A3:Alibaba trade assurance/TT/West Union/Payple/LC/Cash and so on.


Q4:Do you have CE document and other documents for customs clearance?

A4:Yes,we have Original. At first we will show you and And after shipment we will give you CE/Packing list/Commercial Invoice/Sales contract for customs clearance.


Q5:I don't know how to use after I receive or I have problem during use,how to do?

A5:

1) We have detailed user manual with pictures and CD,you can learn step by step.And our user manual.

update every month for your easy learning if there is any update on machine.

2) If have any problem during use,you need our technician to judge

The problem elsewhere will be solved by us. We can provide team viewer

/Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide Door service if you need.
