1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping
HomeHome > Products > Laser Stripping Machine > 1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping
1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping

1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping

Overview Product Description APPLICATION : Metalsurface rust removal, Surfacepaint removal and paint treatment, Surfaceo
Overview
Basic Info.
Model NO. KC-M
Functions Welding Cutting Cleaning
Laser Head Relfar Qilin
Weight 250kg
Advantages Max 300mm Cleaning Width
Dimensions 1400*700*1200mm
Water Chiller S&a
Cooling Type Water Cooling
Fiber Cable 10m / 15m
Controller Relfar Qilin
Auto Wire Feeder Standard
Laser Source Ipg Max Jpt Raycus
Laser Power 1000W 1500W 2000W 3000W
Name Hand Held Fiber Laser Cleaning Machine
Transport Package Wooden Box
Specification 1400*700*1200mm
Trademark KNOPPO
Origin China
HS Code 8456110090
Production Capacity 500 Sets/Month
Product Description
Product Description

1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping

APPLICATION :
Metalsurface rust removal, Surfacepaint removal and paint treatment, Surfaceoil, stains, dirt cleaning, Surfacecoating, clear coating, Weldingsurface / spray surface pretreatment, Stonesurface dust and attachment removal, Rubbermold residue cleaning.
A Metal surface cleaning
B Removal paint of metal surface
C stains cleaning on the surface
D Surface coating cleaning
E Pre-treatment of welding surface cleaning
F Stone surface cleaning
G Rubber mold residue cleaning

1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping

Detailed PhotosRaycus Laser Source and S&A Water ChillerRaycus is largest manufacturer of laser source in China , can weld carbon steel , stainless steel and aluminium etc . Good qualityand long life . Suitablef for 24 hours continuous working.Relfar Laser Cleaning Head
With hot temperature alarm and double protections lens , very sale . small and light , easy to operation.Relfar Control Sytsem
Different cleaning parameters is saved on system , when you weld metal , you need only choose it . Also support multi languages , such as English , Polish , Spainish , Russian , Korean , Japanese , Portugal etc .
France Schineider Electric Parts
European CE standard , good quality and long lifetime . Product Parameters
NODescriptionParameter
1ModelKC-M
2Laser Power1000W 1500W 2000W 3000W
3Laser TypeMAX / Raycus
4Central wavelength1064nm
5Line length10 M
6Cleaning efficiency12 m3/h
7Support languageEnglish, Chinese, Japanese, Korean, Russian, Spanish, Polish
8Cooling TypeWater cooling
9Average Power (W), Max1000W / 1500W/ 2000W/3000W
10Average Power (W), Output Range(If adjustable)0-100
11Pulse-Frequency (KHz),Range20-200
12Scanning Width (mm)10-150/300
13Expected Focal Distance(mm)160mm
14Input Power380V/220V, 50/60H
15Dimensions1300mm×700mm×1150mm
16Weight270KG
Packaging & Shipping
Wooden box package , safedelivery

1500W 2000W Handheld Fiber Laser Cutting Cleaning Welding Machine for Metal Aluminium Stainless Carbon Steel Soldering / Rust Paint Removal Stripping

CertificationsOur fiber laser welding machine have CE certificates , all electric drawing and quality is suitable European standard .After Sales Service*3 years guarantee of the whole machine and we give lifetime maintenance free of charge. *Free training to make sure you master the operating of machine at our factory. * 24 hours online services through Whatsapp, Skype, Email or on the phone. *Engineers available for overseas training and after-sale services. * Friendly English version manual and operation video CD disk.Company Profile

Knoppo Automation is one of the world's leading manufacturers of high-tech industrial laser solutions, dedicated to providing laser intelligent equipment solutions and enabling our customers in various branches around the world to become more efficient and competitive. With more than 15,000 laser cutting systems in the market and a rapidly increasing global base, Knoppo Automation is in a favorable position to serve the international customer base, guaranteeing highest quality and shortest response times in already more than 100 countries. Our focus is on the innovation, continuous improvement and rapid development of technologies, all of which aim to increase efficiencies and flexibility, minimize costs while generating the highest levels of environmental friendliness and sustainability to our all benefit. We aim to provide key technologies and customized integration solutions for Industry 4.0 and smart factories, helping enterprises to make perfect use of the many opportunities arising in the digital age.

The product range not only comprises of flat sheet cutting systems in various designs and dimensions, but also of laser tube cutting systems, CO2 laser cutting engraving machine , laser welding machine etc . With our focused, highly skilled and experienced R & D team and a perfectly equipped and trained systematic after-sales technical department, we truly provide customer-oriented service experience.
